NOSHOK PT40 Series High Accuracy Fixed Range Pressure Transmitter PT40-200PSIG-2-2-45-14, 0 to 200psig, ±0.125% of span, 0 Vdc to 5 Vdc, 3-wire, 7/16-20 male SAE J514 FIG 34B (non-adjustable), DIN form A with 1/2 NPT female conduit
SKU:
PT40-200PSIG-2-2-45-14
Made in the United States
$524.99
Price on request
Was: $582.44
You Save $57.45
Available
Available Sizes
Size7/16"
Pressure Range0 to 200 psi gauge
Process Connection7/16-20 male SAE J514 FIG 34B (non-adjustable)
Media Temperature Range-20 to 212 ºF / -30 to 100 ºC
Typically ships in 3–5 business days from the manufacturer
Need it fast? Call 888-825-8800 — we may be able to expedite your order.
Estimated ship date: calculating...
Sourced from Vetted Suppliers
Every product is quality-checked from certified manufacturers
Technical Specifications
General
| Product Series | PT40 High Accuracy Fixed Range Pressure Transmitter |
|---|---|
| Accuracy | ±0.125% of span, non-linearity best fit straight line per IEC 61298-2 at reference conditions |
| Output Signal | 0 Vdc to 5 Vdc, 3-wire |
| Power Requirement | 10 Vdc to 30 Vdc |
| Brand | NOSHOK |
| Manufacturer Part # | PT40-200PSIG-2-2-45-14 |
| Size | 7/16" |
| Country of Origin | Made in the United States |
Materials & Construction
| Materials of Construction (Wetted Parts) | 316 Stainless Steel with 316 Stainless Steel housing |
|---|
Performance
| Pressure Range | 0 to 200 psi gauge |
|---|---|
| Media Temperature Range | -20 to 212 ºF / -30 to 100 ºC |
Connections
| Process Connection | 7/16-20 male SAE J514 FIG 34B (non-adjustable) |
|---|---|
| Electrical Connection | DIN form A with 1/2 NPT female conduit |
Overview
PT40 Series - High Accuracy Fixed Range Pressure Transmitter
- Gauge, compound, absolute and vacuum ranges from 2 psig to 15,000 psig
- Premium accuracy
- Current and voltage outputs available
- 316 and 17-4PH Stainless Steel wetted parts
- CE compliant to suppress RFI, EMI and ESD
