3/4" Bonomi 8P0132 - 3 Way, Brass, Ball Valve, L-Port, & SR Actuator
(You save $67.42)
Product Description
3/4" Bonomi 8P0132 - Technical Specs
Item
3-Way Ball Valve (L port)
Body Material
Brass
Body Style
3-Way
Connection Type
Threaded (FNPT x FNPT X FNPT)
Size
3/4"
Max. Pressure
400 WOG - 100 WSP
Seat Material
PTFE
Ball Material
Chrome-Plated Brass
Max Process Temp
344 Degrees F
Stem Type
Blowout Proof
Stem Material
Brass
Actuator Action
Spring Return
Sized For
80 PSI of available air pressure
Other Details
Size:
3/4"
