1-1/2" Bonomi 8P0130 - 3-Way, L-Port, FNPT, Brass Body, Actuated Ball Valve, with DA Pneumatic Actuator

Name: 1-1/2" Bonomi 8P0130 - 3-Way, L-Port, FNPT, Brass Body, Actuated Ball Valve, with DA Pneumatic Actuator
Brand: Bonomi Valves
SKU: 8P0130-1-1/2

SKU: 8P0130-1-1/2

Made in Italy

Price on request

Available Sizes

1/4" 3/8" 1/2" 3/4" 1" 1-1/4" 1-1/2" 2" 2-1/2" 3"

Size1-1/2"

Max. Pressure400 WOG - 100 WSP

Body MaterialBrass

Connection TypeThreaded (FNPT x FNPT X FNPT)

PortStandard Port

Ships direct from the manufacturer — call 888-825-8800 for current lead time

Download Specification Sheet (PDF)

Sourced from Vetted Suppliers Every product is quality-checked from certified manufacturers

Need It Fast? Call 888-825-8800

Made-to-order — final sale, see return policy

Expert Support: 888-825-8800

Technical Specifications

General

Item	3-Way Ball Valve (L port)
Size	1-1/2"
Actuation	Double Acting (DA) Pneumatic
Brand	Bonomi Valves
Manufacturer Part #	8P0130-1-1/2
Country of Origin	Made in Italy

Materials & Construction

Body Material	Brass
Body Style	3-Way
Seat Material	PTFE
Ball Material	Chrome-Plated Brass
Stem Type	Blowout Proof
Stem Material	Brass

Performance

Max. Pressure	400 WOG - 100 WSP
Temp. Rating	-4 to 366>
Actuator Supply Pressure	Min. 80 psi and Max. 116 psi

Connections

Port	Standard Port
Connection Type	Threaded (FNPT x FNPT X FNPT)
