1-1/2" NOSHOK 100 Series Acrylonitrile Butadiene Styrene (ABS) & Steel Case Dry Pressure Gauges, 15-120-60-psi/kPa-GL, Steel Panel Mount Case, 60 psi/kPa, 1/8" NPT Back Connection, Glass Lens
SKU:
15-120-60-psi/kPa-GL
Made in the United States
$57.99
Price on request
Was: $75.99
You Save $18.00
Available
Gauge Size1-1/2 in
Pressure Range0 to 60 psi
Connection TypeNational Pipe Thread (NPT)
Typically ships in 3–5 business days from the manufacturer
Need it fast? Call 888-825-8800 — we may be able to expedite your order.
Estimated ship date: calculating...
Sourced from Vetted Suppliers
Every product is quality-checked from certified manufacturers
Technical Specifications
General
| Stock | Yes |
|---|---|
| Type | Dry Pressure Gauge |
| Full Scale Best Fit Straight Line (BFSL) Accuracy (±) | 2.5 % |
| Gauge Size | 1-1/2 in |
| Dial | White background with black primary scale & red secondary scale. UV resistant |
| Case Type | Steel Case Panel Mount |
| Series | 100 |
| Pointer | Molded Plastic |
| Movement | Brass & nylon, or all-brass with highly polished bearing surfaces |
| Warranty | 1 yr |
| Scale Option | psi/kPa Dual Scale |
| Measuring Element | Copper Alloy Bourdon Tube |
| Options | Glass Lens |
| Brand | NOSHOK |
| Manufacturer Part # | 15-120-60-psi/kPa-GL |
| Size | 1-1/2" |
| Country of Origin | Made in the United States |
Materials & Construction
| Lens/Display Material | Acrylic |
|---|---|
| Bezel Material | Chrome-plated steel triangular bezel |
| Case Material | Black painted steel with chrome triangular bezel and U-clamp |
Performance
| Pressure Range | 0 to 60 psi |
|---|
Connections
| Connection Type | National Pipe Thread (NPT) |
|---|---|
| Connection Location | Back |
| Connection Size | 1/8 in |
| Connection Material | Brass |
Overview
100 Series - Acrylonitrile Butadiene Styrene (ABS) & Steel Case Dry Pressure Gauges
- Accurate and reliable general purpose dry gauge with vacuum & compound ranges, and ABS or Steel case. Ideal for applications including hydraulics, pneumatics, medical, pumps, compressors, refrigeration controls and more.
- Multiple connection options are available including panel mount. A wide variety of pressure ranges, scale options, connections sizes, and options including flanges, case options, cover rings, lens materials, pointers, and orifices are also available.
- Cleaning for Oxygen Service (O2) is available only for dry or HL (Halocarbon) filled gauges.
