1/4" Bonomi 8E865LF-00 Ball Valve, 355N LF Direct Mount, 3-Way, Lead-Free Brass, NPT, T-Port with Electric Actuator
SKU:
8E865LF-002-1/4
Made in Italy
$312.99
Price on request
Was: $368.00
You Save $55.01
Available to Order
Select Voltage: 24V AC/DC
Size Range1/4"
Pressure Rating400 psi WOG
Body MaterialLead-Free Brass
End ConnectionNPT Threaded
PortingT-Port
Typically ships in 12–14 business days from the manufacturer
Need it fast? Call 888-825-8800 — we may be able to expedite your order.
Estimated ship date: calculating...
Sourced from Vetted Suppliers
Every product is quality-checked from certified manufacturers
Need It Fast? Call 888-825-8800
Made-to-order — final sale, see return policy
Expert Support: 888-825-8800
Technical Specifications
General
| Item | 3-Way Electrically Actuated Ball Valve |
|---|---|
| Size Range | 1/4" |
| Available Actuator Voltage | 24V AC/DC |
| Duty Cycle | (75% w/ 8 sec. cycle time) 120V AC, (50% w/ 6.5 sec. cycle time) 24V AC/DC |
| Brand | Bonomi Valves |
| Manufacturer Part # | 8E865LF-002-1/4 |
| Size | 1/4" |
| Country of Origin | Made in Italy |
Materials & Construction
| Body Material | Lead-Free Brass |
|---|---|
| Ball Material | Lead-Free Brass |
| Seat Material | PTFE |
| Stem Material | Lead-Free Brass |
| Stem Design | Blowout Proof Stem |
Performance
| Pressure Rating | 400 psi WOG |
|---|---|
| Temp. Rating | -4> |
Connections
| Porting | T-Port |
|---|---|
| End Connection | NPT Threaded |
