Save 26%
2-1/2" NOSHOK 1000 Series Piston Type Differential Pressure Gauge
SKU:
2-1/2-in-NSK-1000-Piston-PG-0-to-100-psid
Made in the United States
Starting at
$314.99
Out of Stock
Select a Model to Order This page shows the full series. Choose a specific model below to view pricing and add to cart.
Available Models
Please select a model to order.
Select a model above to add to cart.
Connection Size1/4 in
Working Pressure [Max]3,000 psi
Connection TypeFemale National Pipe Thread (FNPT)
Storage Temperature (Switch Option) [Min]-40°C / -40°F
Sourced from Vetted Suppliers
Every product is quality-checked from certified manufacturers
Technical Specifications
General
| Type | Differential Pressure Gauge |
|---|---|
| Series | 1000 |
| Lens | Shatter-Resistant Acrylic |
| Dial | Aluminum, white background with black scale. |
| Gauge Size | 2-1/2 in / 6 in |
| Fill Fluids (Optional) | Glycerin |
| Measuring Element | 316 Stainless Steel and Ceramic Piston/Magnet |
| Pointer | Balanced Aluminum, Black Finish |
| Movement | Magnetic |
| AC Voltage | 125 V |
| DC Voltage | 125 V |
| Warranty | 5 yr |
| Brand | NOSHOK |
| Manufacturer Part # | 2-1/2-in-NSK-1000-Piston-PG-0-to-100-psid |
| Country of Origin | Made in the United States |
Materials & Construction
| Case Material | Engineered Plastic |
|---|---|
| Sensor Housing Materials | Aluminum |
| O-Ring and Diaphragm Materials | Nitrile Rubber (NBR) |
| Bezel Material | Engineered Plastic |
| Related Items 102-MFS, 1/4" NPT, Male x Female, 316 Stainless Steel, 0.172" Orifice Hard Seat Mini Valve 402-MFS, 1/4" NPT, Male x Female, 316 Stainless Steel, Hard Seat, 0.187" Orifice Needle Valve 602-MFS, 1/4" NPT, Male x Female, 316 Stainless Steel, Hard Seat, 0.187" Orifice Block and Bleed Valve Options and Accessories | Related Items 102-MFS, 1/4" NPT, Male x Female, 316 Stainless Steel, 0.172" Orifice Hard Seat Mini Valve 402-MFS, 1/4" NPT, Male x Female, 316 Stainless Steel, Hard Seat, 0.187" Orifice Needle Valve 602-MFS, 1/4" NPT, Male x Female, 316 Stainless Steel, Hard Seat, 0.187" Orifice Block and Bleed Valve Options and Accessories |
Performance
| Storage Temperature (Switch Option) [Min] | -40°C / -40°F |
|---|---|
| Storage Temperature (Switch Option) [Max] | 93°C / 200°F |
| Working Pressure [Max] | 3,000 psi |
| Media Temperature Range (Switch Option) | -40 to 93°C / -40 to 200°F |
| Ambient Temperature Range (Switch Option) | -40 to 93°C / -40 to 200°F |
| Ambient Temperature Range (4-20 mA Transmitter Option) | -29 to 66°C / -20 to 150°F |
| Pressure Range | 0 to 100 psid |
| Accuracy (Full Scale on Rising Pressure) | ±3/2/3% |
| Switch Rating | Single Pole Double Throw (SPDT) |
| Power Rating | 3 W |
| Current Rating | 0.25 A |
Connections
| Connection Size | 1/4 in |
|---|---|
| Connection Type | Female National Pipe Thread (FNPT) |
| Connection Location | Back |
