2-1/2" NOSHOK 200 Series Low Pressure Diaphragm Dry Pressure Gauges, 25-200-60-inH2O-GL-SSCR, Black Steel Case, Copper Alloy Internals, 60 inH2O, 1/4" NPT Male Bottom Connection, Glass Lens, 304 Stainless Steel Cover Ring
SKU:
25-200-60-inH2O-GL-SSCR
Made in the United States
$84.99
Price on request
Was: $112.93
You Save $27.94
Available
Available Models
3 psi, Recalibrator Lens
5 psi, 0.3 mm Brass Threaded Orifice
10 inH2O, 0.3mm Brass Threaded Orifice
10 inH2O, Glass Lens, Black Cover Ring
10 psi, Set Pointer
15 inH2O, 0.3mm Brass Threaded Orifice
30 inH2O, 0.3mm Brass Threaded Orifice
30 inH2O, Glass Lens, Black Cover Ring
60 inH2O, 0.3 mm Brass Threaded Orifice
60 inH2O, Glass Lens, 304 Stainless Steel Cover Ring
60 inH2O
Connection Size1/4 in
Pressure Range0 to 60 inH2O
Connection TypeNational Pipe Thread (NPT)
Typically ships in 3–5 business days from the manufacturer
Need it fast? Call 888-825-8800 — we may be able to expedite your order.
Estimated ship date: calculating...
Sourced from Vetted Suppliers
Every product is quality-checked from certified manufacturers
Technical Specifications
General
| Stock | Yes |
|---|---|
| Type | Low Pressure Gauge |
| Series | 200 |
| Full Scale Accuracy (±) | 1.6 % |
| Gauge Size | 2-1/2 in |
| Dial | Aluminum, white background with black scale. UV resistant |
| Case Type | Steel, Bottom Connection |
| Pointer | Black Finished Aluminum |
| Movement | Brass and Nickel-Silver with Highly Polished Bearing Surfaces |
| Warranty | 1 yr |
| Options | Glass Lens, 304 Stainless Steel (SS) Cover Ring |
| Brand | NOSHOK |
| Manufacturer Part # | 25-200-60-inH2O-GL-SSCR |
| Size | 2-1/2" |
| Country of Origin | Made in the United States |
Materials & Construction
| Lens/Display Material | Acrylic |
|---|---|
| Case Material | Black Painted Steel |
Performance
| Pressure Range | 0 to 60 inH2O |
|---|
Connections
| Connection Type | National Pipe Thread (NPT) |
|---|---|
| Connection Size | 1/4 in |
| Connection Location | Bottom |
| Connection Material | Brass |
Overview
200 Series - Low Pressure Diaphragm Dry Pressure Gauges
- Sensitive capsule-type non-fillable dry gauge
- Black painted Steel, Stainless Steel and impact-resistant ABS case
- Copper alloy and Brass wetted parts
