Save 46%
2-1/2" NOSHOK 400/500 Series All Stainless Steel Dry & Liquid Filled Pressure Gauges, 25-410-30-psi-SG, 304 SS Case, 316 SS Internals, 30 psi, 1/4" NPT Male Back Connection, Safety Glass Lens
SKU:
25-410-30-psi-SG
Made in the United States
$101.99
Price on request
Was: $191.80
You Save $89.81
Available
Connection Size1/4 in
Pressure Range0 to 30 psi
Connection TypeNational Pipe Thread (NPT)
Typically ships in 3–5 business days from the manufacturer
Need it fast? Call 888-825-8800 — we may be able to expedite your order.
Estimated ship date: calculating...
Sourced from Vetted Suppliers
Every product is quality-checked from certified manufacturers
Technical Specifications
General
| Type | Pressure Gauge |
|---|---|
| Full Scale Best Fit Straight Line (BFSL) Accuracy (±) | 1.6 % |
| Dial | Aluminum, White Background with Black Scale. Ultraviolet (UV) Resistant. |
| Gauge Size | 2-1/2 in |
| Case Type | All Stainless Steel (SS), Dry/Fillable, Back Connection |
| Scale Option | psi Single Scale |
| Measuring Element | 316 Stainless Steel C-Type Bourdon Tube |
| Pointer | Balanced Aluminum, Black Finish |
| Movement | Stainless Steel with Highly Polished Bearing Surfaces |
| Options | Safety Glass Lens |
| Warranty | 1 yr |
| Brand | NOSHOK |
| Manufacturer Part # | 25-410-30-psi-SG |
| Size | 2-1/2" |
| Country of Origin | Made in the United States |
Materials & Construction
| Cover Ring Material | Polished 304 Stainless Steel |
|---|---|
| Lens/Display Material | Trogamide |
| Case Material | Polished 304 Stainless Steel with Safety Relief Plug |
Performance
| Pressure Range | 0 to 30 psi |
|---|
Connections
| Connection Type | National Pipe Thread (NPT) |
|---|---|
| Connection Size | 1/4 in |
| Connection Location | Back |
| Connection Material | Stainless Steel |
Overview
400/500 Series - All Stainless Steel Dry & Liquid Filled Pressure Gauges
- Corrosion-resistant fillable dry or liquid-filled gauge
- Vacuum and compound ranges through 0 psi to 20,000 psi
- 316 Stainless Steel wetted parts
- Cleaning for Oxygen Service (O2) is available only for dry or HL (Halocarbon) filled gauges
- For gauges with MIP, GY40 fill is standard for liquid filled gauges
