Save 23%
2" NOSHOK 100 Series Acrylonitrile Butadiene Styrene (ABS) & Steel Case Dry Pressure Gauges, 20-148-30-vac/kPa, ABS Square Panel Mount Case, Copper Alloy Internals, 30 vac/kPa, 1/8" NPT Male/10-32 Female Back Connection
SKU:
20-148-30-vac/kPa
Made in the United States
$32.99
Price on request
Was: $43.29
You Save $10.30
Available
Available Models
ABS Case, Copper Alloy Internals, 30 vac/bar, 1/4" NPT Bottom Connection
ABS Case, Copper Alloy Internals, 30 vac/kPa, 1/4" NPT Bottom Connection
ABS Case, Copper Alloy Internals, 30 vac/kPa, 1/8" NPT Bottom Connection
ABS Case, Copper Alloy Internals, 30 vac/kg/cm², 1/4" NPT Bottom Connection
ABS Case, Copper Alloy Internals, 30 vac/bar, 1/4" NPT Back Connection
ABS Case, Copper Alloy Internals, 30 vac/kPa, 1/4" NPT Back Connection Vacuum Gauge
ABS Case, Copper Alloy Internals, 30 vac/kPa, 1/8" NPT Back Connection
ABS Square Panel Mount Case, Copper Alloy Internals, 30 vac, 1/8" NPT Male/10-32 Female Back Connection
ABS Square Panel Mount Case, Copper Alloy Internals, 30 vac/kPa, 1/8" NPT Male/10-32 Female Back Connection
ABS Case, Copper Alloy Internals, 30 vac/kPa, 1/4" NPT Back Connection, Black Front Flange
ABS Case, Copper Alloy Internals, 30 vac/kPa, 1/4" NPT Back Connection, Steel Panel Mount Clamp
ABS Case, Copper Alloy Internals, 30 vac/kPa, 1/4" NPT Back Connection, Chrome Front Flange
Steel Panel Mount Case, 30 vac/kPa, 1/4" NPT Back Connection
ABS Case, Copper Alloy Internals, 30 vac/bar, 1/4" NPT Back Connection, Chrome Front Flange, 304 Stainless Steel Bezel
Gauge Size2 in
Pressure Range0 to 30 psi
Connection LocationBack
Ships direct from the manufacturer — call 888-825-8800 for current lead time
Sourced from Vetted Suppliers
Every product is quality-checked from certified manufacturers
Technical Specifications
General
| Type | Dry Pressure Gauge |
|---|---|
| Full Scale Best Fit Straight Line (BFSL) Accuracy (±) | 2.5 % |
| Gauge Size | 2 in |
| Dial | White background with black primary scale & red secondary scale. UV resistant |
| Case Type | Square Acrylonitrile Butadiene Styrene (ABS), Panel Mount (2" only) |
| Series | 100 |
| Pointer | Molded Plastic |
| Movement | Brass & nylon, or all-brass with highly polished bearing surfaces |
| Warranty | 1 yr |
| Scale Option | kPa Scale |
| Measuring Element | Copper Alloy Bourdon Tube |
| Brand | NOSHOK |
| Manufacturer Part # | 20-148-30-vac/kPa |
| Size | 2" |
| Country of Origin | Made in the United States |
Materials & Construction
| Lens/Display Material | Acrylic |
|---|
Performance
| Pressure Range | 0 to 30 psi |
|---|
Connections
| Connection Location | Back |
|---|---|
| Connection Size | 1/8 in. National Pipe Thread (NPT)/10-32 Female, Brass |
Overview
100 Series - Acrylonitrile Butadiene Styrene (ABS) & Steel Case Dry Pressure Gauges
- Accurate and reliable general purpose dry gauge with vacuum & compound ranges, and ABS or Steel case. Ideal for applications including hydraulics, pneumatics, medical, pumps, compressors, refrigeration controls and more.
- Multiple connection options are available including panel mount. A wide variety of pressure ranges, scale options, connections sizes, and options including flanges, case options, cover rings, lens materials, pointers, and orifices are also available.
- Cleaning for Oxygen Service (O2) is available only for dry or HL (Halocarbon) filled gauges.
