4" Jomar Valve JF-100SG-LH, 2 Piece, Full Port, Dezincification Resistant Lead-Free Brass, Soldered Ends, Stainless Steel Ball & Stem, Latch Lock Handle, 600 WOG Ball Valve
Brand : Jomar Valve
MSRP: $1,201.76
$858.99
(You save
$342.77
)
- SKU:
- 100-121SSG-LH
- Size:
- 4"
- Size Dropdown:
- True
- Processing Time:
- 1-2 Days
3/4" Jomar Valve JF-100SLBG 2-Piece Ball Valve Technical Specs
Features
- Dezincification Resistant Brass Alloy
- Gland Follower and Single O-Ring Stem Design
- Blow-Out Proof Stem
- 100% Leak Tested
- IAPMO Certified - NSF 61 & NSF 372 Certified
- FM Approval (1/4" - 2")
- Wetted Surfaces Contain Less than .25% Content
Certifications/Approvals
- UL Listed up to 175 PSI (1/4" - 2")
- MHKZ - Manual valves
- YRPV - Gas shut-off valves
- IAPMO Certified
- NSF 61-8
- NSF 372
- Uniform Plumbing Code (cUPC)
- IAPMO/ANSI Z1157-2014
- NSF/ANSI 14-2014
- FM Approval (1/2" - 1-1/2" 600 WOG, 2" 500 WOG)
- MSS SP-110
- ASME/ANSI B16.18
Technical Specifications
Item
Ball Valve
Size
3/4"
Port
Full Port
Design Type
2-Piece
End Connection
Solder
Body Material
Lead-Free Brass - C46500
Ball Material
304 Stainless Steel
Handle Type
T-Handle
Seat Material
PTFE
Stem Material
304 Stainless Steel
Stem Design
Blowout-Proof, Long Neck Bonnet
Max Pressure
600 psi WOG, 150 psi steam
Max Temp
-20°F to 300°F
