4" Bonomi M8E730LLV*-0**-4 30°/ 60°/ 90° V-Port Ball Valve, 3 Piece, Direct Mount, 2-Way, Stainless Steel, NPT Threaded, with Electric Actuator

Name: 4" Bonomi M8E730LLV*-0**-4 30°/ 60°/ 90° V-Port Ball Valve, 3 Piece, Direct Mount, 2-Way, Stainless Steel, NPT Threaded, with Electric Actuator
Brand: Bonomi Valves
SKU: M8E730LLV3-022-4

SKU: M8E730LLV3-022-4

$7,250.99 Was: $8,544.00 You Save $1,293.01

Available to Order

Available Sizes

1/2" 3/4" 1" 1-1/2" 2" 2-1/2" 3" 4"

Select V-Ball:: 30° V-Ball

Select Voltage/Positioner/Battery Backup: 24V AC/DC with Positioner

Size4"

Max. Pressure1440 psi, 250 psi steam

Body MaterialCF8M Stainless Steel

Connection TypeNPT Threaded

Typically ships in 12–14 business days from the manufacturer

Need it fast? Call 888-825-8800 — we may be able to expedite your order.

Estimated ship date: calculating...

Download Specification Sheet (PDF)

Sourced from Vetted Suppliers Every product is quality-checked from certified manufacturers

Need It Fast? Call 888-825-8800

Made-to-order — final sale, see return policy

Expert Support: 888-825-8800

Technical Specifications

General

Item	2-Way Electrically Actuated Ball Valve (V-Port)
Size	4"
Ball Options	30>< , 60>< , 90><
Max. Process Temp.	150>
Available Actuator Package	12V AC/DC
Duty Cycle	75% Duty Cycle
Brand	Bonomi Valves
Manufacturer Part #	M8E730LLV3-022-4

Materials & Construction

Body Material	CF8M Stainless Steel
Body Style	3-Piece
Seat Material	TFM-4215
Ball Material	316 Stainless Steel
Stem Material	316 Stainless Steel

Performance

Max. Pressure	1440 psi, 250 psi steam
NEMA Rating	NEMA 4

Connections

Connection Type	NPT Threaded
