6" NOSHOK 800 Series Precision Test Pressure Gauges, 60-800-2000-psi, 304 Stainless Steel Case, 316 Stainless Steel Tube/Brass Socket, 0 to 2,000 psi, 1/4" NPT Bottom Connection
SKU:
60-800-2000-psi
Made in the United States
$894.99
Price on request
Was: $1,193.04
You Save $298.05
Available
Connection Size1/4 in
Pressure Range0 to 2,000 psig
Connection TypeNational Pipe Thread (NPT)
Media Temperature Range1-40 to 180 ºF
Typically ships in 3–5 business days from the manufacturer
Need it fast? Call 888-825-8800 — we may be able to expedite your order.
Estimated ship date: calculating...
Sourced from Vetted Suppliers
Every product is quality-checked from certified manufacturers
Technical Specifications
General
| Type | Pressure Gauge |
|---|---|
| Series | 800 |
| Full Scale Accuracy (±) | 0.25 % |
| Lens | Instrument Glass |
| Dial | Aluminum, white mirrored background with black scale. |
| Gauge Size | 6 in |
| Scale Option | psi Single Scale |
| Measuring Element | Beryllium copper Bourdon tube to 1,000 psi, 316 SS Bourdon tube 1,500 psi to 6,000 psi |
| Case Type | Stainless Steel (SS) Case, Bottom Connection |
| Pointer | Adjustable Knife-Edge Pointer |
| Movement | Brass with jeweled bearings nickel-silver pinion gear and shafts |
| Warranty | 1 yr |
| Brand | NOSHOK |
| Manufacturer Part # | 60-800-2000-psi |
| Size | 6" |
| Country of Origin | Made in the United States |
Materials & Construction
| Cover Ring Material | 304 Stainless Steel |
|---|---|
| Case Material | 304 Stainless Steel |
Performance
| Media Temperature Range1 | -40 to 180 ºF |
|---|---|
| Ambient Temperature Range2 | -40 to 140 ºF |
| Pressure Range | 0 to 2,000 psig |
| Figure Primary Scale Pressure | 200 psi |
| Graduation Primary Scale Pressure | 10 psi |
Connections
| Connection Type | National Pipe Thread (NPT) |
|---|---|
| Connection Size | 1/4 in |
| Connection Location | Bottom |
| Connection Material | Brass |
Overview
800 Series - Precision Test Pressure Gauges
- Highly accurate dry gauge
- Vacuum and compound ranges through 0 psi to 6,000 psi
- Beryllium Copper, 316 Stainless Steel, and Brass wetted parts
- Cleaning for Oxygen Service (O2) is available only for dry or HL (Halocarbon) filled gauges
