Save 13%
STC AR5000-10 - 1" NPT Air Regulator (280 SCFM)
SKU:
AR5000-10
$76.99
Price on request
Was: $88.76
You Save $11.77
Available to Order
Port Size1" NPT
Body MaterialAluminum
Temperature LimitsTemperature Limits
Gauge Port Size1/4" NPT
Typically ships in 1 business days from the manufacturer
Need it fast? Call 888-825-8800 — we may be able to expedite your order.
Estimated ship date: calculating...
Sourced from Vetted Suppliers
Every product is quality-checked from certified manufacturers
Technical Specifications
General
| Output Ranges | 7 - 125 psi |
|---|---|
| Max Supply | 150 PSI (9.9 kgf/cm^2) |
| Filter | 5 Micron Filter (Option); 25 Micron (Standard Sintered Brass Filter) |
| Seals | NBR |
| 40 - 140°F | 40 - 140°F |
| Brand | STC Valve |
| Manufacturer Part # | AR5000-10 |
| Size | 1" |
Materials & Construction
| Body Material | Aluminum |
|---|
Performance
| Flow Capacity | 280 SCFM (8000 LPM) |
|---|---|
| Temperature Limits | Temperature Limits |
Connections
| Port Size | 1" NPT |
|---|---|
| Gauge Port Size | 1/4" NPT |
Dimensions & Weight
| Weight | 2.62 lbs |
|---|
Standards & Certifications
See Specification Sheet
