Save 15%
Bonomi 8E864LF-00 Series - Ball Valve, Lead Free, Brass, 2-way, FNPT Threaded, Full Port, with Electric Actuator
SKU:
BNM-8E864LF-00
Starting at
$293.99
Out of Stock
Select a Size to Order This page shows the full valve series. Choose a specific pipe size below to view pricing and add to cart.
Please select a size to order.
Select a size above to add to cart.
Pressure Rating600 WOG
Body MaterialLead Free Brass
End ConnectionFNPT Threaded
PortFull Port
Sourced from Vetted Suppliers
Every product is quality-checked from certified manufacturers
Need It Fast? Call 888-825-8800
Made-to-order — final sale, see return policy
Expert Support: 888-825-8800
Technical Specifications
General
| Item | 2-Way Electrically Actuated Ball Valve |
|---|---|
| Design Type | 2 piece, Direct Mount |
| Control | On/Off |
| Available Voltages | 24V AC/DC and 110V AC |
| Actuation Type | Electric (Fail in Place) |
| Brand | Bonomi Valves |
| Manufacturer Part # | BNM-8E864LF-00 |
Materials & Construction
| Body Material | Lead Free Brass |
|---|---|
| Ball Material | Lead Free Brass |
| Seat Material | P.T.F.E |
| Packing Material | EPDM/Viton |
| Stem Design | Blowout Proof |
Performance
| Pressure Rating | 600 WOG |
|---|---|
| Temp. Rating | +23°F to +131°F |
| NEMA Rating | NEMA 4 |
Connections
| Port | Full Port |
|---|---|
| End Connection | FNPT Threaded |
Standards & Certifications
See Specification Sheet
