ControlAir Type 700 Precision Air Pressure Regulator, 429-829-043, 700-BCH, 0 - 15 Psig (0 - 1.0 Bar), 1/4" NPT, High Bleed
Brand : ControlAir
MSRP: $145.70
$141.99
(You save
$3.71
)
- SKU:
- 429-829-043
- Size Dropdown:
- True
- Processing Time:
- 14
- Specific Date:
- Days
ControlAir Type 700 429-829-043, 700-BCH Precision Air Pressure Regulator
Features:
- 1/4”, 3/8”, 1/2” NPT/BSP Porting
- High Flow Capacity
- Allows flows up to 80 scfm (2,264 Nl/min)
- Sensitive
- Senses output pressure deviations to within
- 1/8 inch water column pressure
- Stable Output
- Dampening action of aspirator tube makes this regulator insensitive to changes in flow
- On-Line Maintenance
- Can be serviced without removal from air line
High Flow Capacity & Accurate Pressure Control
- The Type 700 is designed for applications that require high flow capacity and accurate process control. A poppet valve which is balanced by utilizing a rolling diaphragm insures a constant output pressure even during wide supply pressure variations. Stability of regulated pressure is maintained under varying flow conditions through the use of an aspirator tube which adjusts the air supply in accordance with the flow velocity.
Technical Specifications
Port Size
1/4"
Output Range
0 - 15 psig (0 - 1.0 bar)
Flow Capacity
80 scfm (2,264 Nl/min)
Exhaust Capacity
4 scfm (120 NL/min)
Sensitivity
1/8" in. (3.2 mm)
Max. Supply Pressure
250 psig (17 bar)
Supply Pressure Sensitivity
Less than 0.1 psig for a 100 psig change (0.007 bar for a 6.7 bar change)
Air Consumption
Less than 12.0 scfh (340 Nl/hr)
Ambient Temperature Limits
-40° to +160°F '(-40° to 71°C)
Weight
1.625 lbs (0.74 kg)
Mounting
Pipe, Panel, Bracket
Body Material
Diecast Aluminum Alloy
Other Material
Stainless steel, Brass, Plated Steel Acetal, Buna-N, Polyester, Phenolic Plastic
Part Number
429-829-043
High Bleed
Yes
