ControlAir Type 345 Series Pneumatic Air Filter, 429-843-054, 345-DXF, 1/2" National Pipe Thread, 5 Micron Filter
Brand : ControlAir
MSRP: $159.65
$155.99
(You save
$3.66
)
- SKU:
- 429-843-054
- Size Dropdown:
- True
- Processing Time:
- 14
- Specific Date:
- Days
ControlAir Type 345 Series 429-843-054, 345-DXF Pneumatic Air Filter
Features:
- ¼” & ½” port sizes
- 40 or 5 Micron Filter
- Autodrain Capabilities
- Low Temperature Option: Down to -62°F
Options & Features (See Specification Sheet For Full List):
Type 345 Pneumatic Air Filter
The Type 345 Filter unit is a 40-micron (Optional 5 Micron) depth filter that removes dirt, moisture and other particles from air and gas lines. Robustly constructed of die-cast aluminum with a baked epoxy finish, this unit stands up in corrosive operating conditions. This filter is an economical alternative for air supply line applications that don’t require a pressure reducing regulator. Available in 1/4″ and 1/2″ NPT porting, manual and automatic drain. Optional 5-micron filter.
Technical Specifications
Port Size
1/2" NPT
Max. Supply Pressure
150 psig (10 bar), 250 psig (17 bar)
Max. Flow Capacity- 1/2" Ports
200 scfm (5, 660 Nl/min)
Max. Flow Capacity- 1/4" Ports
80 scfm (2, 264 Nl/min)
Ambient Temperature Limits
-62° to 194°F (-52° to 90°C), 0° to 160°F (-18° to 71°C), 32° to 160°F (0° to 71°C)
Filter
5 micron, 40 micron
Cv Value
0.5, 2.5
Mounting
Pipe, Bracket, Through Body
Operating Media
Air, Inert Gas, Sweet Natural Gas
Weight
1.0 lb (0.4 kg), 1.5 lbs (0.68 kg)
Body Materials
Diecast Aluminum Alloy
Other Materials
Polyethylene, Nitrile Elastomer, Nylon Fabric
Part Number
429-843-054
5 Micron Filter
Yes
