ControlAir Type 345 Series Pneumatic Air Filter, CA-T345-FLTR-14-12-NPT, Type 345, 1/4" NPT
Select a Model to Order This page shows the full series. Choose a specific model below to view pricing and add to cart.
Select a model above to add to cart.
Technical Specifications
General
| Filter | 5 micron, 40 micron |
|---|---|
| Cv Value | 0.5, 2.5 |
| Mounting | Pipe, Bracket, Through Body |
| Part Number | CA-T345-FLTR-14-12-NPT |
| Brand | ControlAir |
| Manufacturer Part # | CA-T345-FLTR-14-12-NPT |
| Country of Origin | Made in the United States |
Materials & Construction
| Body Materials | Diecast Aluminum Alloy |
|---|---|
| Other Materials | Polyethylene, Nitrile Elastomer, Nylon Fabric |
Performance
| Max. Supply Pressure | 150 psig (10 bar), 250 psig (17 bar) |
|---|---|
| Ambient Temperature Limits | -62° to 194°F (-52° to 90°C), 0° to 160°F (-18° to 71°C), 32° to 160°F (0° to 71°C) |
| Operating Media | Air, Inert Gas, Sweet Natural Gas |
Connections
| Port Size | 1/2" NPT, 1/4" NPT |
|---|---|
| Max. Flow Capacity- 1/2" Ports | 200 scfm (5, 660 Nl/min) |
| Max. Flow Capacity- 1/4" Ports | 80 scfm (2, 264 Nl/min) |
Dimensions & Weight
| Weight | 1.0 lb (0.4 kg), 1.5 lbs (0.68 kg) |
|---|
Overview
ControlAir Type 345 Series CA-T345-FLTR-14-12-NPT, Pneumatic Air Filter
Features:
- ¼” & ½” port sizes
- 40 or 5 Micron Filter
- Autodrain Capabilities
- Low Temperature Option: Down to -62°F
Options & Features (See Specification Sheet For Full List):
Type 345 Pneumatic Air Filter
The Type 345 Filter unit is a 40-micron (Optional 5 Micron) depth filter that removes dirt, moisture and other particles from air and gas lines. Robustly constructed of die-cast aluminum with a baked epoxy finish, this unit stands up in corrosive operating conditions. This filter is an economical alternative for air supply line applications that don’t require a pressure reducing regulator. Available in 1/4″ and 1/2″ NPT porting, manual and automatic drain. Optional 5-micron filter.
