ControlAir Type 410 Series High Precision Pressure Regulator, 429-841-453, 410-BBN, 0 - 10 Psig (0 - 0.7 Bar), 1/4" NPT, Non-Relieving
SKU:
429-841-453
Made in the United States
$115.99
Price on request
Was: $119.20
You Save $3.21
Available to Order
Port Size1/4" NPT
Effect of Supply Pressure VariationLess than 0.2 psig (0.01 BAR) for 25 psi (1.7 BAR) change
Temperature Limits0° to 160°F (-18° to 71°C)
Typically ships in 14 business days from the manufacturer
Need it fast? Call 888-825-8800 — we may be able to expedite your order.
Estimated ship date: calculating...
Sourced from Vetted Suppliers
Every product is quality-checked from certified manufacturers
Technical Specifications
General
| Exhaust Capacity | 0.1 scfm (2.8 Nl/min) downstream pressure 5 psig (0.3 bar) above set point |
|---|---|
| Sensitivity | 1/2" (1.3 cm) water column |
| Air Consumption | Less than 6 scfh (170 Nl/min) |
| Mounting | Pipe, panel or optional bracket |
| Output Range | 0 - 10 Psig (0 - 0.7 Bar) |
| Part Number | 429-841-453 |
| Non-Relieving | Yes |
| Brand | ControlAir |
| Manufacturer Part # | 429-841-453 |
| Size | 1/4" |
| Country of Origin | Made in the United States |
Materials & Construction
| Materials | Body: Diecast aluminum alloy |
|---|
Performance
| Effect of Supply Pressure Variation | Less than 0.2 psig (0.01 BAR) for 25 psi (1.7 BAR) change |
|---|---|
| Max. Supply Pressure | 250 psig (17 bar) |
| Temperature Limits | 0° to 160°F (-18° to 71°C) |
Connections
| Port Size | 1/4" NPT |
|---|
Overview
ControlAir Type 410 Series 429-841-453, 410-BBN High Precision Pressure Regulator
Features
- Stable Output & Reliability – Consistently meets control requirements under changing operating conditions.
- Corrosion Resistant Construction – Die-cast housings are finished with iridate and epoxy paint.
- Low Droop at High Flow Levels – Aspirator design helps maintain set pressure and minimize “droop” at higher flow levels.
- High Quality Level – Each regulator receives a pressure, leak and flow test at the factory prior to shipment.
- Low Cost – This economical unit is ideal for high volume OEM applications.
Reliable, All Purpose Air Regulation
The ControlAir Type 410 is a high precision regulator designed to provide reliable performance under variable operating conditions. This quality unit is ideal as an economical alternative for control of industrial process applications. The regulation characteristics of the Type 410 have been proven to be superior to comparable competitive units. Durable materials and corrosion resistant construction provide reliable operation in harsh industrial environments.
