Jomar Valve A850L Series, 3-Way, L-Port, Full Port, Stainless Steel, Flanged, ISO Mounting Pad, 1000 WOG Ball Valve

Name: Jomar Valve A850L Series, 3-Way, L-Port, Full Port, Stainless Steel, Flanged, ISO Mounting Pad, 1000 WOG Ball Valve
Brand: Jomar Valve
SKU: JMR-A850L

SKU: JMR-A850L

Starting at $231.99

Select a Size to Order This page shows the full valve series. Choose a specific pipe size below to view pricing and add to cart.

Available Sizes

1/4" 3/8" 1/2" 3/4" 1" 1-1/4" 1-1/2" 2"

Size1/4" to 2"

Max Pressure(1/4" to 1") 1000 psi WOG, (1-1/4" to 2") 800 psi WOG

Body MaterialCF8M Stainless Steel

End ConnectionFlange

PortFull Port

Sourced from Vetted Suppliers Every product is quality-checked from certified manufacturers

Need It Fast? Call 888-825-8800

30-Day Returns · see policy

Expert Support: 888-825-8800

Technical Specifications

General

Item	3-Way Ball Valve (L-Port)
Size	1/4" to 2"
Design Type	2-Piece with ISO Mounting Pad
Brand	Jomar Valve
Manufacturer Part #	JMR-A850L

Materials & Construction

Body Material	CF8M Stainless Steel
Ball Material	316 Stainless Steel
Stem Material	316 Stainless Steel
Stem Design	Blowout Proof Stem

Performance

Max Pressure	(1/4" to 1") 1000 psi WOG, (1-1/4" to 2") 800 psi WOG

Connections

Port	Full Port
End Connection	Flange

Download Specification Sheet (PDF)
