NOSHOK 400 Series Mechanical Heavy-Duty Pressure Switches, 1 Single Pole Double Throw (SPDT), 7/16-20 Society of Automotive Engineers (SAE) J514 FIG 34B, 3 to 4,600 psig, DIN EN 175301-803 Form
SKU:
NKS-400-PS-SPDT-7/16-20-SAE
Made in the United States
Starting at
$125.99
Out of Stock
Select a Size to Order This page shows the full valve series. Choose a specific pipe size below to view pricing and add to cart.
Process Connection Size7/16-20
Electrical ConnectionDIN EN 175301-803 Form A
Sourced from Vetted Suppliers
Every product is quality-checked from certified manufacturers
Technical Specifications
General
| Type | Mechanical Switch |
|---|---|
| Series | 400 |
| Switching Function | Single Pole Double Throw (SPDT) Snap-Action Micro Switch |
| Switch Adjustable Range | 3 to 30 psig |
| Switch Point | Field Adjustable and/or Factory Set |
| Hysteresis | Piston Type, 2% to 8% of Adjustment Range Full Scale |
| Service Life | < 1,000,000 Load Cycles |
| Measuring Element | Nitrile Rubber (NBR) diaphragm ≤ 230 psig |
| Shock According to International Electrotechnical Commission (IEC) 60068-2-27 | 30 g |
| Vibration According to International Electrotechnical Commission (IEC) 60068-2-6 | 10 g |
| Warranty | 1 |
| Brand | NOSHOK |
| Manufacturer Part # | NKS-400-PS-SPDT-7/16-20-SAE |
| Country of Origin | Made in the United States |
Materials & Construction
| Housing Material | Zinc Die-Cast |
|---|
Performance
| Environmental Rating | IP65 - DIN EN 175301-803 Form A |
|---|---|
| Electromagnetic Rating | European Conformity (CE) Compliant to European Standard (EN) 73/23/EWG Radio Frequency Interference (RFI), Electromagnetic Interference (EMI) and Electrostatic Discharge (ESD) Protection |
| Contact Rating | 6A @ 12/24 Vdc |
Connections
| Electrical Connection | DIN EN 175301-803 Form A |
|---|---|
| Process Connection | Society of Automotive Engineers (SAE) Male, Non-Adjustable |
| Process Connection Size | 7/16-20 |
Dimensions & Weight
| Weight | 0.66 lb |
|---|
Overview
400 Series - Mechanical Heavy-Duty Pressure Switches
- Switch adjustment ranges from vacuum through 4,600 psig depending on model
- Standard Zinc-plated Steel with NBR diaphragm (< 225 psig); Steel piston with NBR seal (> 225 psig) wetted parts
- SPDT snap-action switch
- RoHS compliant
