Save 24%
NOSHOK 6" 400/500 Series All Stainless Steel Dry & Liquid Filled Pressure Gauges, 304 Stainless Steel Case, 316 Stainless Steel Internals, 5000 psi, 1/2" MNPT Bottom Connection
SKU:
NOSHOK-400/500-6-in-5000-psi
Made in the United States
Starting at
$1,260.99
Out of Stock
Select a Model to Order This page shows the full series. Choose a specific model below to view pricing and add to cart.
Available Models
Please select a model to order.
Select a model above to add to cart.
Connection Size1/2 in
Pressure Range0 to 5000 psi
Connection TypeNPT
Buying for a facility?
Custom quote, volume pricing, or Net 30 terms available.
Request a Formal Quote or call 888-825-8800
Sourced from Vetted Suppliers
Every product is quality-checked from certified manufacturers
Technical Specifications
General
| Type | Pressure Gauge |
|---|---|
| Full Scale Best Fit Straight Line (BFSL) Accuracy (±) | 1 % |
| Dial | Aluminum, White Background with Black Scale. Ultraviolet (UV) Resistant |
| Gauge Size | 6 in |
| Case Type | All Stainless Steel (SS), Dry/Fillable, Bottom connection |
| Scale Option | psi Single Scale |
| Measuring Element | 316 Stainless Steel C-Type Bourdon Tube |
| Pointer | Balanced micro-adjustable aluminum, black finish |
| Movement | Stainless Steel with Highly Polished Bearing Surfaces an Internal Zero Stop is Standard |
| Warranty | 1 yr |
| Brand | NOSHOK |
| Manufacturer Part # | NOSHOK-400/500-6-in-5000-psi |
| Country of Origin | Made in the United States |
Materials & Construction
| Cover Ring Material | Polished 304 Stainless Steel |
|---|---|
| Lens/Display Material | Laminated Safety Glass |
| Case Material | 304 Stainless Steel with Safety Relief Plug, Optional 316 Stainless Steel |
Performance
| Pressure Range | 0 to 5000 psi |
|---|
Connections
| Connection Type | NPT |
|---|---|
| Connection Size | 1/2 in |
| Connection Location | Bottom |
Overview
400/500 Series - All Stainless Steel Dry & Liquid Filled Pressure Gauges
- Corrosion-resistant fillable dry or liquid-filled gauge
- Vacuum and compound ranges through 0 psi to 20,000 psi
- 316 Stainless Steel wetted parts
- Cleaning for Oxygen Service (O2) is available only for dry or HL (Halocarbon) filled gauges
- For gauges with MIP, GY40 fill is standard for liquid filled gauges
