NOSHOK PT20 Series General Purpose Fixed Range Pressure Transmitter, 0 to 10000psig, 1/4 NPT Male
SKU:
NSK-PT20-PT-0-to-10000-psig-1/4-NPT-M
Made in the United States
Starting at
$181.99
Out of Stock
Select a Size to Order This page shows the full valve series. Choose a specific pipe size below to view pricing and add to cart.
Pressure Range0 to 10000 psi gauge
Process Connection1/4 NPT Male
Media Temperature Range32 to 176 ºF / 0 to 80 ºC
Sourced from Vetted Suppliers
Every product is quality-checked from certified manufacturers
Technical Specifications
General
| Product Series | PT20 General Purpose Fixed Range Pressure Transmitter |
|---|---|
| Accuracy | ±0.5% of span, non-linearity best fit straight line per IEC 61298-2 at reference conditions |
| Output Signal | 4 mA to 20 mA, 2-wire |
| Power Requirement | 8 Vdc to 30 Vdc |
| Brand | NOSHOK |
| Manufacturer Part # | NSK-PT20-PT-0-to-10000-psig-1/4-NPT-M |
| Country of Origin | Made in the United States |
Materials & Construction
| Materials of Construction (Wetted Parts) | 316 Stainless Steel with 316 Stainless Steel housing |
|---|
Performance
| Pressure Range | 0 to 10000 psi gauge |
|---|---|
| Environmental Rating | IP65 |
| Media Temperature Range | 32 to 176 ºF / 0 to 80 ºC |
Connections
| Process Connection | 1/4 NPT Male |
|---|---|
| Electrical Connection | DIN form C |
Overview
PT20 Series - General Purpose Fixed Range Pressure Transmitters
- Gauge, compound, absolute and vacuum ranges from 1 psig to 10,000 psig
- Current and voltage outputs available
- 316 and 13-8PH Stainless Steel wetted parts
- RoHS compliant
- CE compliant to suppress RFI, EMI and ESD
