NOSHOK PT20 Series General Purpose Fixed Range Pressure Transmitter PT20-200PSIG-1-2-10-8, 0 to 200psig, G 1/4 B EN 837, DIN Form A
SKU:
PT20-200PSIG-1-2-10-8
Made in the United States
$168.99
Price on request
Was: $187.07
You Save $18.08
Available
Size1/4"
Pressure Range0 to 200 psi gauge
Process ConnectionG 1/4 B EN 837
Media Temperature Range32 to 176 ºF / 0 to 80 ºC
Typically ships in 3–5 business days from the manufacturer
Need it fast? Call 888-825-8800 — we may be able to expedite your order.
Estimated ship date: calculating...
Sourced from Vetted Suppliers
Every product is quality-checked from certified manufacturers
Technical Specifications
General
| Product Series | PT20 General Purpose Fixed Range Pressure Transmitter |
|---|---|
| Accuracy | ±0.5% of span, non-linearity best fit straight line per IEC 61298-2 at reference conditions |
| Output Signal | 0 Vdc to 5 Vdc, 3-wire |
| Power Requirement | 8 Vdc to 30 Vdc |
| Brand | NOSHOK |
| Manufacturer Part # | PT20-200PSIG-1-2-10-8 |
| Size | 1/4" |
| Country of Origin | Made in the United States |
Materials & Construction
| Materials of Construction (Wetted Parts) | 316 Stainless Steel with 316 Stainless Steel housing |
|---|
Performance
| Pressure Range | 0 to 200 psi gauge |
|---|---|
| Environmental Rating | IP65 |
| Media Temperature Range | 32 to 176 ºF / 0 to 80 ºC |
Connections
| Process Connection | G 1/4 B EN 837 |
|---|---|
| Electrical Connection | DIN form A |
Overview
PT20 Series - General Purpose Fixed Range Pressure Transmitters
- Gauge, compound, absolute and vacuum ranges from 1 psig to 10,000 psig
- Current and voltage outputs available
- 316 and 13-8PH Stainless Steel wetted parts
- RoHS compliant
- CE compliant to suppress RFI, EMI and ESD
