NOSHOK PT30 Series High Performance Fixed Range Pressure Transmitter, 0 to 1000psig, 0 Vdc to 5 Vdc, 3-wire, 1/4 NPT male
SKU:
NSK-PT30-PT-0-to-1000-psig-0-Vdc-to-5-Vdc-3-wire-1/4-NPT-M
Made in the United States
Starting at
$335.99
Out of Stock
Select a Size to Order This page shows the full valve series. Choose a specific pipe size below to view pricing and add to cart.
Pressure Range0 to 1000 psi gauge
Process Connection1/4 NPT male
Media Temperature Range-22 to 221 ºF / -30 to 105 ºC
Sourced from Vetted Suppliers
Every product is quality-checked from certified manufacturers
Technical Specifications
General
| Product Series | PT30 High Performance Fixed Range Pressure Transmitter |
|---|---|
| Accuracy | ±0.25% of span, non-linearity best fit straight line per IEC 61298-2 at reference conditions |
| Output Signal | 0 Vdc to 5 Vdc, 3-wire |
| Power Requirement | 12 Vdc to 36 Vdc |
| Brand | NOSHOK |
| Manufacturer Part # | NSK-PT30-PT-0-to-1000-psig-0-Vdc-to-5-Vdc-3-wire-1/4-NPT-M |
| Country of Origin | Made in the United States |
Materials & Construction
| Materials of Construction (Wetted Parts) | 316 Stainless Steel with 304 Stainless Steel housing |
|---|
Performance
| Pressure Range | 0 to 1000 psi gauge |
|---|---|
| Environmental Rating | IP67 |
| Media Temperature Range | -22 to 221 ºF / -30 to 105 ºC |
Connections
| Process Connection | 1/4 NPT male |
|---|---|
| Electrical Connection | bayonet 4 pin |
Overview
PT30 Series - High Performance Fixed Range Pressure Transmitter
- Gauge, compound, absolute and vacuum ranges from 2 psig to 15,000 psig
- Premium accuracy
- Compact size
- Current and voltage outputs available
- 316 Stainless Steel wetted parts
- RoHS compliant
- CE compliant to suppress RFI, EMI and ESD
- cULus pending
