NOSHOK PT40 Series High Accuracy Fixed Range Pressure Transmitter, 0 to 2000psig, DIN form A with 1/2 NPT female conduit
SKU:
NSK-PT40-PT-0-to-2000-psig-DIN-form-A-1/2-NPT
Made in the United States
Starting at
$508.99
Out of Stock
Select a Size to Order This page shows the full valve series. Choose a specific pipe size below to view pricing and add to cart.
Available Sizes
Pressure Range0 to 2000 psi gauge
Process Connection1/4 NPT male
Media Temperature Range-20 to 212 ºF / -30 to 100 ºC
Sourced from Vetted Suppliers
Every product is quality-checked from certified manufacturers
Technical Specifications
General
| Product Series | PT40 High Accuracy Fixed Range Pressure Transmitter |
|---|---|
| Accuracy | ±0.25% of span, non-linearity best fit straight line per IEC 61298-2 at reference conditions |
| Output Signal | 4 mA to 20 mA, 2-wire |
| Power Requirement | 10 Vdc to 30 Vdc |
| Brand | NOSHOK |
| Manufacturer Part # | NSK-PT40-PT-0-to-2000-psig-DIN-form-A-1/2-NPT |
| Country of Origin | Made in the United States |
Materials & Construction
| Materials of Construction (Wetted Parts) | 316 Stainless Steel with 316 Stainless Steel housing |
|---|
Performance
| Pressure Range | 0 to 2000 psi gauge |
|---|---|
| Media Temperature Range | -20 to 212 ºF / -30 to 100 ºC |
Connections
| Process Connection | 1/4 NPT male |
|---|---|
| Electrical Connection | DIN form A with 1/2 NPT female conduit |
Overview
PT40 Series - High Accuracy Fixed Range Pressure Transmitter
- Gauge, compound, absolute and vacuum ranges from 2 psig to 15,000 psig
- Premium accuracy
- Current and voltage outputs available
- 316 and 17-4PH Stainless Steel wetted parts
- CE compliant to suppress RFI, EMI and ESD
