NOSHOK PT40 Series High Accuracy Fixed Range Pressure Transmitter PT40-1000PSIG-2-5-2-14, 0 to 1000psig, ±0.125% of span, 0 Vdc to 10 Vdc, 3-wire, 1/4 NPT male, DIN form A with 1/2 NPT female conduit
SKU:
PT40-1000PSIG-2-5-2-14
Made in the United States
$524.99
Price on request
Was: $582.44
You Save $57.45
Available
Available Sizes
Size1/4"
Pressure Range0 to 1000 psi gauge
Process Connection1/4 NPT male
Media Temperature Range-20 to 212 ºF / -30 to 100 ºC
Typically ships in 3–5 business days from the manufacturer
Need it fast? Call 888-825-8800 — we may be able to expedite your order.
Estimated ship date: calculating...
Sourced from Vetted Suppliers
Every product is quality-checked from certified manufacturers
Technical Specifications
General
| Product Series | PT40 High Accuracy Fixed Range Pressure Transmitter |
|---|---|
| Accuracy | ±0.125% of span, non-linearity best fit straight line per IEC 61298-2 at reference conditions |
| Output Signal | 0 Vdc to 10 Vdc, 3-wire |
| Power Requirement | 14 Vdc to 30 Vdc |
| Brand | NOSHOK |
| Manufacturer Part # | PT40-1000PSIG-2-5-2-14 |
| Size | 1/4" |
| Country of Origin | Made in the United States |
Materials & Construction
| Materials of Construction (Wetted Parts) | 316 Stainless Steel with 316 Stainless Steel housing |
|---|
Performance
| Pressure Range | 0 to 1000 psi gauge |
|---|---|
| Media Temperature Range | -20 to 212 ºF / -30 to 100 ºC |
Connections
| Process Connection | 1/4 NPT male |
|---|---|
| Electrical Connection | DIN form A with 1/2 NPT female conduit |
Overview
PT40 Series - High Accuracy Fixed Range Pressure Transmitter
- Gauge, compound, absolute and vacuum ranges from 2 psig to 15,000 psig
- Premium accuracy
- Current and voltage outputs available
- 316 and 17-4PH Stainless Steel wetted parts
- CE compliant to suppress RFI, EMI and ESD
