NOSHOK PT40 Series High Accuracy Fixed Range Pressure Transmitter PT40-300PSIG-2-1-8-25, 0 to 300psig, ±0.125% of span, 4 mA to 20 mA, 2-wire, 1/2 NPT male, M12 x 1 4 pin
SKU:
PT40-300PSIG-2-1-8-25
Made in the United States
$521.99
Price on request
Was: $579.40
You Save $57.41
Available
Available Sizes
Size1/2"
Pressure Range0 to 300 psi gauge
Process Connection1/2 NPT male
Media Temperature Range-20 to 212 ºF / -30 to 100 ºC
Typically ships in 3–5 business days from the manufacturer
Need it fast? Call 888-825-8800 — we may be able to expedite your order.
Estimated ship date: calculating...
Sourced from Vetted Suppliers
Every product is quality-checked from certified manufacturers
Technical Specifications
General
| Product Series | PT40 High Accuracy Fixed Range Pressure Transmitter |
|---|---|
| Accuracy | ±0.125% of span, non-linearity best fit straight line per IEC 61298-2 at reference conditions |
| Output Signal | 4 mA to 20 mA, 2-wire |
| Power Requirement | 10 Vdc to 30 Vdc |
| Brand | NOSHOK |
| Manufacturer Part # | PT40-300PSIG-2-1-8-25 |
| Size | 1/2" |
| Country of Origin | Made in the United States |
Materials & Construction
| Materials of Construction (Wetted Parts) | 316 Stainless Steel with 316 Stainless Steel housing |
|---|
Performance
| Pressure Range | 0 to 300 psi gauge |
|---|---|
| Environmental Rating | IP67 |
| Media Temperature Range | -20 to 212 ºF / -30 to 100 ºC |
Connections
| Process Connection | 1/2 NPT male |
|---|---|
| Electrical Connection | M12 x 1 4 pin |
Overview
PT40 Series - High Accuracy Fixed Range Pressure Transmitter
- Gauge, compound, absolute and vacuum ranges from 2 psig to 15,000 psig
- Premium accuracy
- Current and voltage outputs available
- 316 and 17-4PH Stainless Steel wetted parts
- CE compliant to suppress RFI, EMI and ESD
