NOSHOK PT41 Series High Pressure Fixed Range Pressure Transmitter, 0 to 23000 psig, 0 VDC to 10 VDC, 3-Wire
SKU:
NSK-PT41-PT-0-to-23000-psig-0-VDC-to-10-VDC-3-Wire
Made in the United States
Starting at
$1,465.99
Out of Stock
Select a Model to Order This page shows the full series. Choose a specific model below to view pricing and add to cart.
Available Models
PT41-23000PSIG-1-5-6-8
PT41-23000PSIG-1-5-6-18
PT41-23000PSIG-1-5-6-14
PT41-23000PSIG-1-5-6-25
PT41-23000PSIG-1-5-6-36
PT41-23000PSIG-1-5-6-3
PT41-23000PSIG-1-5-6-16
PT41-23000PSIG-2-5-6-8
PT41-23000PSIG-2-5-6-18
PT41-23000PSIG-2-5-6-14
PT41-23000PSIG-2-5-6-25
PT41-23000PSIG-2-5-6-36
PT41-23000PSIG-2-5-6-3
PT41-23000PSIG-2-5-6-16
Please select a model to order.
Select a model above to add to cart.
Pressure Range0 to 23000 psi gauge
Process Connection9/16-18 UNF 2B high pressure
Media Temperature Range0 to 80°C / 32 to 175°F
Buying for a facility?
Custom quote, volume pricing, or Net 30 terms available.
Request a Formal Quote or call 888-825-8800
Sourced from Vetted Suppliers
Every product is quality-checked from certified manufacturers
Technical Specifications
General
| Product Series | PT41 High Pressure Fixed Range Pressure Transmitter |
|---|---|
| Accuracy | ±0.5% of span, non-linearity best fit straight line per IEC 61298-2 at reference conditions |
| Output Signal | 0 Vdc to 10 Vdc, 3-wire |
| Power Requirement | 14 Vdc to 30 Vdc |
| Brand | NOSHOK |
| Manufacturer Part # | NSK-PT41-PT-0-to-23000-psig-0-VDC-to-10-VDC-3-Wire |
| Country of Origin | Made in the United States |
Materials & Construction
| Materials of Construction | 316 Stainless Steel with 316 Stainless Steel housing |
|---|
Performance
| Pressure Range | 0 to 23000 psi gauge |
|---|---|
| Environmental Rating | IP67 |
| Media Temperature Range | 0 to 80°C / 32 to 175°F |
Connections
| Process Connection | 9/16-18 UNF 2B high pressure |
|---|---|
| Electrical Connection | Bayonet 6 pin |
