NOSHOK PT41 Series High Pressure Fixed Range Pressure Transmitter PT41-23000PSIG-2-2-6-36, 0 to 23000 psig, 0 VDC to 5 VDC, 3-Wire, ±0.25% Span, Integral Cable 3 Ft
SKU:
PT41-23000PSIG-2-2-6-36
Made in the United States
$3,390.99
Price on request
Available
Available Models
PT41-23000PSIG-1-2-6-8
PT41-23000PSIG-1-2-6-18
PT41-23000PSIG-1-2-6-14
PT41-23000PSIG-1-2-6-25
PT41-23000PSIG-1-2-6-36
PT41-23000PSIG-1-2-6-3
PT41-23000PSIG-1-2-6-16
PT41-23000PSIG-2-2-6-8
PT41-23000PSIG-2-2-6-18
PT41-23000PSIG-2-2-6-14
PT41-23000PSIG-2-2-6-25
PT41-23000PSIG-2-2-6-36
PT41-23000PSIG-2-2-6-3
PT41-23000PSIG-2-2-6-16
Size9/16"
Pressure Range0 to 23000 psi gauge
Process Connection9/16-18 UNF 2B high pressure
Media Temperature Range32 to 175°F / 0 to 80°C
Typically ships in 3–5 business days from the manufacturer
Need it fast? Call 888-825-8800 — we may be able to expedite your order.
Estimated ship date: calculating...
Buying for a facility?
Custom quote, volume pricing, or Net 30 terms available.
Request a Formal Quote or call 888-825-8800
Sourced from Vetted Suppliers
Every product is quality-checked from certified manufacturers
Technical Specifications
General
| Product Series | PT41 High Pressure Fixed Range Pressure Transmitter |
|---|---|
| Accuracy | ±0.25% of span, non-linearity best fit straight line per IEC 61298-2 at reference conditions |
| Output Signal | 0 Vdc to 5 Vdc, 3-wire |
| Power Requirement | 10 Vdc to 30 Vdc |
| Brand | NOSHOK |
| Manufacturer Part # | PT41-23000PSIG-2-2-6-36 |
| Size | 9/16" |
| Country of Origin | Made in the United States |
Materials & Construction
| Materials of Construction | 316 Stainless Steel with 316 Stainless Steel housing |
|---|
Performance
| Pressure Range | 0 to 23000 psi gauge |
|---|---|
| Environmental Rating | IP68 |
| Media Temperature Range | 32 to 175°F / 0 to 80°C |
Connections
| Process Connection | 9/16-18 UNF 2B high pressure |
|---|---|
| Electrical Connection | Integral cable 3 ft |
