STC 2W200C ATEX Explosion Proof Solenoid Coil, DIN 43650A, 3 m Cable

Name: STC 2W200C ATEX Explosion Proof Solenoid Coil, DIN 43650A, 3 m Cable
Brand: STC Valve
SKU: 2W200C-1-ATEX

SKU: 2W200C-1-ATEX

$207.99 Was: $242.37 You Save $34.38

Available to Order

Available Sizes

DIN 43650A (Form A), 14.5mm Armature DIN 43650A (Form A), Diamond Body DIN 43650A (Form A), 20mm Armature DIN 43650A (Form A), 14.5mm Armature, 36mm Wide

Voltage & Power Level: 12VDC, 9.9W (Level 3, T4)

SizeDIN 43650A (Form A), 14.5mm Armature, 36mm Wide

Typically ships in 1 business days from the manufacturer

Need it fast? Call 888-825-8800 — we may be able to expedite your order.

Estimated ship date: calculating...

Sourced from Vetted Suppliers Every product is quality-checked from certified manufacturers

Need It Fast? Call 888-825-8800

Expert Support: 888-825-8800

Technical Specifications

Brand	STC Valve
Manufacturer Part #	2W200C-1-ATEX
Size	DIN 43650A (Form A), 14.5mm Armature, 36mm Wide

Applications	ATEX explosion proof coil for 2P050, 2S025-050, 3S020-035, 2S160-250, 2W160-250, 2R130-500, 2RS130-500, 2RSO130-500, 2RO130-500 (valve body not included)
Electrical Connection	DIN 43650A connection, 36mm wide, with 3 m three-wire cable and sleeve
ATEX Marking	Ex II 2 G Ex mb II T4 Gb / Ex II 2 D Ex tb IIIC T130C Db
Max Media Temperature	176F (80C)
Ambient Temperature	-4 to 122F (-20 to 50C)
Protection Class	IP65
Coil Insulation	F Class
Coil Duty Cycle	100% ED
Compliance	RoHS Compliant
