Description Other Details STC 3A120-420 Series Technical Specifications Description3 Way 2 Position Double Pilot Air Valve Port & MountingBody Ported, Stackable (Stacking Hardware Included) Action & MotionAir Piloted, Two Position, 3 Way Operating Pressure28" Hg to 115PSI Working Medium40 micron filtered air, inert gas Maximum Pressure150PSI Operating Temperature-5 to 80°C with non-freezing medium Pilot Pressure-40 to 115PSI Body MaterialAnodized AluminumSeal MaterialNBR (Buna N)Cv-SCFM @ 100 PSI- Discover more about the STC 3A120-420 Series Pilot Operated Air ValveSpecification SheetSolenoid Valves Owner's Manual Size Dropdown: True
Description Other Details STC 3A120-420 Series Technical Specifications Description3 Way 2 Position Double Pilot Air Valve Port & MountingBody Ported, Stackable (Stacking Hardware Included) Action & MotionAir Piloted, Two Position, 3 Way Operating Pressure28" Hg to 115PSI Working Medium40 micron filtered air, inert gas Maximum Pressure150PSI Operating Temperature-5 to 80°C with non-freezing medium Pilot Pressure-40 to 115PSI Body MaterialAnodized AluminumSeal MaterialNBR (Buna N)Cv-SCFM @ 100 PSI- Discover more about the STC 3A120-420 Series Pilot Operated Air ValveSpecification SheetSolenoid Valves Owner's Manual Size Dropdown: True
Sale Quick Overview STC Valve STC 3A120-1/8" NPT Pilot Operated Air Valves- Double Pilot, 3-Way, 2-Position STC 3A120-1/8" NPT Technical Specifications Description3 Way 2 Position Double Pilot Air Valve Port MSRP: $32.45 Was: Starting At: $27.99 Add to Cart
Sale Quick Overview STC Valve STC 3A220-1/4" NPT Pilot Operated Air Valves- Double Pilot, 3-Way, 2-Position STC 3A220-1/4" NPT Technical Specifications Description3 Way 2 Position Double Pilot Air Valve Port MSRP: $33.12 Was: Starting At: $28.99 Add to Cart
Sale Quick Overview STC Valve STC 3A320-3/8" NPT Pilot Operated Air Valves- Double Pilot, 3-Way, 2-Position STC 3A320-3/8" NPT Technical Specifications Description3 Way 2 Position Double Pilot Air Valve Port MSRP: $39.21 Was: Starting At: $33.99 Add to Cart
Sale Quick Overview STC Valve STC 3A420-1/2" NPT Pilot Operated Air Valves- Double Pilot, 3-Way, 2-Position STC 3A420-1/2" NPT Technical Specifications Description3 Way 2 Position Double Pilot Air Valve Port MSRP: $66.91 Was: Starting At: $57.99 Add to Cart
