STC AC1010-M5 - M5 Stacking Air Filter- Regulator- Lubricator (3 SCFM)
SKU:
STC-AC1010-M5
$64.99
Price on request
Out of Stock
Available Models
Port SizeM5/10-32
Body MaterialAluminum
Temperature Limits40 - 140°F
Gauge Port Size1/16 Rc (PT)
Typically ships in 1 business days from the manufacturer
Need it fast? Call 888-825-8800 — we may be able to expedite your order.
Sourced from Vetted Suppliers
Every product is quality-checked from certified manufacturers
Technical Specifications
General
| Output Ranges | 7 - 100 PSI |
|---|---|
| Max Supply | 150 PSI (9.9 kgf/cm^2) |
| Filter | 25 Micron Standard Sintered Brass Filter |
| Seals | NBR |
| Brand | STC Valve |
| Manufacturer Part # | STC-AC1010-M5 |
Materials & Construction
| Body Material | Aluminum |
|---|---|
| Bowl Material | Polycarbonate |
Performance
| Flow Capacity | 3 SCFM (90 LPM) |
|---|---|
| Temperature Limits | 40 - 140°F |
Connections
| Port Size | M5/10-32 |
|---|---|
| Gauge Port Size | 1/16 Rc (PT) |
Dimensions & Weight
| Weight | 0.48 lbs |
|---|
Standards & Certifications
See Specification Sheet
