1" Bonomi 8P3LSRPVC- PVC, L-Port, Full Port, Ball Valve with Spring Return Pneumatic Actuator
SKU:
8P3LSRPVC-1
$648.99
Price on request
Was: $764.00
You Save $115.01
Available to Order
Size1"
Pressure Rating232 PSI at 73F
Body MaterialPVC
End ConnectionComes with Threaded (FNPT) and Socket Weld connection
PortingL-Port
Typically ships in 12–14 business days from the manufacturer
Need it fast? Call 888-825-8800 — we may be able to expedite your order.
Estimated ship date: calculating...
Sourced from Vetted Suppliers
Every product is quality-checked from certified manufacturers
Need It Fast? Call 888-825-8800
Made-to-order — final sale, see return policy
Expert Support: 888-825-8800
Technical Specifications
General
| Item | 3-Way Pneumatically Actuated Ball Valve |
|---|---|
| Design Type | Multi-Port |
| Air Supply Needed | 80 PSI |
| Actuation Type | Spring Return |
| Brand | Bonomi Valves |
| Manufacturer Part # | 8P3LSRPVC-1 |
| Size | 1" |
Materials & Construction
| Body Material | PVC |
|---|---|
| Ball Material | PVC |
| Seat Material | P.T.F.E. |
| Packing Material | None. O-rings present in PVC valves |
| Stem Design | Non-blowout Proof |
Performance
| Pressure Rating | 232 PSI at 73F |
|---|---|
| Valve Temp. Rating | 73F |
| Act. Temp Rating | Standard (-4F;+185F), High (-4F;+302F), Low (-40F;+185F) |
Connections
| Porting | L-Port |
|---|---|
| Port | Full Port |
| End Connection | Comes with Threaded (FNPT) and Socket Weld connection |
Standards & Certifications
See Specification Sheet
