3" Bonomi 8P0140 - 3 Way, Stainless Steel, L-Port, Ball Valve with DA Actuator
(You save $396.36)
Product Description
3" Bonomi 8P0140 - Technical Specs
Item
3-Way Ball Valve with Double Acting Actuator
Port Configuration
L-Port (Standard)
Body Material
Stainless Steel (CF8M)
Body Style
3-Way
Connection Type
Threaded (FNPT x FNPT X FNPT)
Size
3"
Max. Pressure
800psi
Seat Material
RTFE
Ball Material
316 Stainless Steel
Temp Range
-4F to 450F
Stem Type
Blowout Proof
Stem Material
316 Stainless Steel
Actuator Action
Double Acting
Sized For
80 PSI of Available Air Pressure
Learn More About the Bonomi 8P0140
Other Details
Size:
3"
