Save 15%
Bonomi 8P3LSRPVC Series - PVC, L-Port, Full Port, Ball Valve with Spring Return Pneumatic Actuator
SKU:
BNM-8P3LSRPVC
Starting at
$499.99
Out of Stock
Select a Size to Order This page shows the full valve series. Choose a specific pipe size below to view pricing and add to cart.
Pressure Rating232 PSI at 73F
Body MaterialPVC
End ConnectionComes with Threaded (FNPT) and Socket Weld connection
PortingL-Port
Sourced from Vetted Suppliers
Every product is quality-checked from certified manufacturers
Need It Fast? Call 888-825-8800
Made-to-order — final sale, see return policy
Expert Support: 888-825-8800
Technical Specifications
General
| Item | 3-Way Pneumatically Actuated Ball Valve |
|---|---|
| Design Type | Multi-Port |
| Air Supply Needed | 80 PSI |
| Actuation Type | Spring Return |
| Brand | Bonomi Valves |
| Manufacturer Part # | BNM-8P3LSRPVC |
Materials & Construction
| Body Material | PVC |
|---|---|
| Ball Material | PVC |
| Seat Material | P.T.F.E. |
| Packing Material | None. O-rings present in PVC valves |
| Stem Design | Non-blowout Proof |
Performance
| Pressure Rating | 232 PSI at 73F |
|---|---|
| Valve Temp. Rating | 73F |
| Act. Temp Rating | Standard (-4F;+185F), High (-4F;+302F), Low (-40F;+185F) |
Connections
| Porting | L-Port |
|---|---|
| Port | Full Port |
| End Connection | Comes with Threaded (FNPT) and Socket Weld connection |
Standards & Certifications
See Specification Sheet
